LED點光源碟形-雙層防水
|
品型號 Product Model |
LC-DGY-X03 |
|
輸入電源 Input Voltage |
DC24V |
|
電源頻率 Freqency Range |
50HZ-60HZ |
|
功率因數 Power Factor |
＞9.0 |
|
LED驅動方式 LED Driving Mode |
外置恒流電源 |
|
LED壽命 LED Life |
50000H |
|
LED顏色 LED Color |
紅，綠，藍，黃，白，暖白，七彩，全彩 |
|
配光方式 Light Design |
LED+透光亞克力 |
|
光束角 Beam Angle |
120 |
|
LED功率 LED Power |
3W |
|
LED結點溫升 LED Node Temperature |
＜65°C |
|
工作溫度 Working Temperature |
-40°C- +55°C |
|
防護等級 IP Grade |
IP67 |
|
外殼材質 Shell Material |
鋁合金底座，高分子PC外罩 |
|
電源連接線 Power Cables |
|
|
燈具尺寸 SIZE |
圓80*高60 |
|
燈具照度 LM |
250LM |
|
產品認證 Product Certification |
檢驗報告 |
靈創
